BigBrain

Reference brains are essential tools in brain mapping research, making it possible to relate data to an anatomical standard space. However, the available reference brains have been restricted to the macroscopic scale, and do not provide information at the microscopic scale. BigBrain is an ultrahigh-resolution three-dimensional (3D) model of a human brain with resolution of 20 micrometers, close to the size of individual neurons, the result of collaborations between our lab and the German Forschungszentrum Jülich as part of the European Human Brain Project.

First published in 2013, BigBrain was created from the reconstruction of 7404 histological sections obtained by cutting a paraffin- embedded brain of a 65 year old male. This histological processing was done using a large-scale microtome in Julich. Histological defects including rips, tears, folds, distortion (shear), stain inhomogeneity, crystallization, as well as missing and displaced pieces were corrected using both manual and automatic repairs to restore the integrity of all sections, and then the 3D reconstruction of the whole brain as a contiguous volume was carried out. Massive calculations were carried out on high-performance computing (HPC) facilities within the Compute Canada network. The reconstruction of the 3D model brain takes advantage of recent progress in computing capacities and image analysis to overcome many challenges, including the highly folded cerebral cortex and the sheer size of the brain, with its 86 billion neurons. The dataset is very large in memory compared to previous brain atlases because of the higher resolution, a total of 1 Terabyte.

BigBrain is also provided as a free, publicly available tool that provides considerable neuroanatomical insight into the human brain, thereby allowing the extraction of microscopic data for modeling and simulation. Existing brain atlases do not allow extraction of information at the level of cortical layers, columns, microcircuits or neurons.  However, anatomical information at the microscopic scale is crucial in order to understand the neurobiological basis of memory, language, emotions or other neural processes. BigBrain could make it possible to better understand brain organization, potentially integrating information across the microscopic and macroscopic levels, linking data at the level of cells with their specific connectivity to the level of cognitive systems and the whole brain. BigBrain enables testing of hypotheses on optimal path lengths between interconnected cortical regions or on the spatial organization of genetic patterning, redefining the traditional neuroanatomical maps such as those of Brodmann and von Economo.

2

bigbrain_a3d_nosurf

bigbrain_parcellated_coronal

bigbrain_a3d_hippocampus_zoom



Ongoing work on BigBrain within our lab and with collaborators includes section-to-section inhomogeneity correction (optical balancing), 3D tissue classification, cortical surface extraction, automated analysis of laminar structure in the cerebral cortex, and manual as well as automated parcellation algorithms.

For more information about BigBrain, consult the article published in Science or posters of ongoing research:

  • Amunts, Katrin, et al., 2013. An ultrahigh-resolution 3D human brain model. Science. [article]
  • Lewis, Lindsay B., et al., 2014. BigBrain: Initial tissue classification and surface extraction. Poster presented at Organization for Human Brain Mapping (OHBM); Hamburg, Germany. [poster]
  • Wagstyl, Konrad, et al., 2016. BigBrain: Automated analysis of laminar structure in the cerebral cortex. Poster presented at Organization for Human Brain Mapping (OHBM); Geneva, Switzerland. [poster]
  • Lepage, Claude, et al., 2016. BigBrain: From Artifact Corrections, Alignment, and Optical-Balancing to Segmentation and Surface Extraction. Poster presented at Toward a Super-Big Brain: promises and pitfalls of microstructural imaging.  Quebec Bio-Imaging Network (QBIN); Montreal, Quebec.



Obtain the BigBrain data.



View the BigBrain.
